Switch with central zero 2no 32a 230/400v

Model : F62N32C – 2NO rotary switch with central position “0”

Rated current : 32 A

Rated voltage : 230–400 V AC (50–60 Hz)

Switching positions : “I” – “0” – “II” (2 alternative closed contacts)

Mounting : 2 modules on DIN EN 60715 (DIN 35) rail

Occupied modules : 2

Standards : CEI EN 60947-3 / CEI EN 60669-1

Degree of protection : IP20

Operating temperature : –10 °C to +40 °C

Max. operating capacity : AC‑22 – up to 30 000 operations

Connections : upper terminals

Dimensions : Height 83 mm × Width 35.6 mm × Depth 74 mm

Cable section : up to 10–16 mm²
