Compact Constant Current Electronic Power Supply for LED WP01-P FLAT 12W 350mA

The WP01-P FLAT 12W 350mA power supply is designed to efficiently power LED lighting systems in constant current. Ideal for indoor installations, it offers advanced protection against overloads and short circuits, with flicker-free technology, which guarantees stable and flicker-free lighting. Its compact structure makes it ideal for small spaces and its energy efficiency makes it an economical and reliable solution.

Main features:

• Usage : Designed for indoor freestanding use with IP20 protection rating, ideal for indoor applications.
• Insulation : Complies with Class II , ensuring protection against electric shock from direct and indirect contact.
• Passive PFC : Includes passive power factor correction , improving energy efficiency.
• Protections : Equipped with protections against short circuits , overloads , and extra mains voltages , for greater reliability and operational safety.
• Cables : Comes with pre-installed 160mm long input and output cables , making installation easy.
• Flicker-free technology : Ensures stable and comfortable lighting, without flickering, improving visual comfort.

Technical specifications:

• Output power : 10-14W
• Output voltage : 27-42V
• Output current : 350 mA constant
• Maximum output voltage : 55V
• Power Factor (PF) : 0.82
• Efficiency : 84%
• Maximum input current : 0.08A
• Input voltage : 220-240V AC
• Frequency : 50/60 Hz

Operating conditions:

• Ambient temperature (ta) : -20/+50 °C
• Maximum temperature (tc) : 85°C

Dimensions and Weight:

• Dimensions : Compact , perfect for installations in limited spaces.

Packaging:

• Inner/Master : 1/100

Advantages:

• Compact Design : Easy to install in small spaces.
• Full Protection : Provides reliable protection against short circuits and overloads.
• Flicker-free : Flicker-free technology ensures stable lighting, ideal for professional and home environments.
• Energy efficiency : With an efficiency of 84%, it reduces energy consumption, improving overall savings.

The WP01-P FLAT 12W 350mA power supply is the ideal solution for LED lighting systems, combining compact design, reliable protection and comfortable, stable lighting.
