ABB S802PV-SP10 5ka 2-pole circuit breaker

The ABB S802PV-SP10 circuit breaker is designed for the protection of photovoltaic systems, in particular for parallel strings.

Main features:

• Rated current (In): 10 A
• Rated operating voltage (Ue): up to 800 V DC
• Rated insulation voltage (Ui): 1500 V DC
• Rated breaking capacity (Icu): 5 kA at 800 V DC
• Number of poles: 2
• Intervention feature: SP
• Regulatory compliance: IEC/EN 60947-2

This switch is ideal for high voltage DC circuits, providing reliable protection for photovoltaic systems.
