Series 11 modular twilight relay 12 16 a

Finder Series 11 – Modular Twilight Relay 12/16A – MPN 01100

The Finder Series 11 twilight relay with code 01100 is a modular DIN rail device, designed to automatically switch on electrical loads (e.g. lights) based on the level of ambient light. Ideal for the automation of outdoor, public, domestic and industrial lighting systems, it allows energy savings and convenience without the use of timers.

✅ Main features

• Model : Finder 011.00

• Series : 11

• Type : Modular twilight relay

• Mounting : on 35mm DIN rail

• Brightness sensor : integrated photocell

• Intervention range : adjustable from 1 to 100 lux

• Rated current : 12 A ( 011.00.0.240.0000 ) / 16 A (higher versions)

• Output contact : 1 SPST contact (NO)

⚙️ Technical specifications

• Power supply voltage : 230 V AC – 50/60 Hz

• Absorption :

• Light threshold adjustment : via front potentiometer

• Switchable power : up to 2,500 W resistive

• Mechanical lifespan : over 1 million operations

• Operating temperature : –20°C to +50°C

• Connection : screw terminals

• Degree of protection : IP20
