Power relay 2 contacts 16a

Finder Power Relay Series 62 – 2 Changeover Contacts 16A – 24V DC

MPN Code: 623290240000

⚙️ General description

The Finder 62.32 power relay, with two changeover contacts (DPDT), is designed for industrial, civil and home automation applications where high switching reliability is required. With a 24V DC coil and a switching capacity of up to 16A per contact , this relay is ideal for controlling resistive or slightly inductive loads.

✅ Technical features

• Coil voltage : 24 V DC

• Number of contacts : 2 (exchange – DPDT)

• Rated contact current : 16 A

• Contact type : AgCdO (silver cadmium oxide)

• Max. switching voltage : up to 400 V AC

• Relay type : electromechanical, high power

• Coil consumption : approx. 54 mA

• Mechanical life : > 10 million operations

• Electrical life : > 100,000 cycles (at full load)

• Activation time : 11 ms

• Release time : 4ms

• Reinforced insulation between coil and contacts

• Operating temperature : –40°C ÷ +70°C

🔧 Assembly and dimensions

• Mounting type : on socket with 4.8 mm faston or soldering on PCB

• Compatibility : with Finder 92 series bases

• Compact size : perfect for electrical panels

🧩 Applications

• Industrial Automation

• Control of motors, pumps, fans

• HVAC Systems

• Civil and industrial electrical panels

• Home automation and supervision systems

📦 Product Benefits

• High reliability and durability over time

• Safe switching of loads up to 16 A

• High isolation between power and control circuits

• Easy integration thanks to standardized assembly
