Differential circuit breaker btdin45 1p+n type a - in. 16a - idn. 0.03a

BTicino GA8813A16 – BTDIN45 RCBO switch 1P+N, Type A, 16 A, 30 mA
Combined magnetothermal and differential protection device:

• Rated current (In) : 16 A

• Differential current (Idn) : 0.03 A (30 mA), type A (protection on pulsating direct currents)

• Intervention curve : type C

• Breaking capacity : 4.5 kA

• Power supply : 230 V AC

• Protected poles : 1 pole + neutral (2 DIN modules)

• Degree of protection : IP20

• Dimensions : L 35.6 mm × H 83 mm × D 76 mm

• Permitted cable section : up to 25/35 mm²

• Compliant with EN/IEC 61009‑1, suitable for personal protection and prevention of overloads/short circuits
