Spot2.4 8w 230v 30k 29° ant

Outdoor Projector Spot 2.4 - 8W 230V AC 3000K Optics 29° Anthracite

The Spot 2.4 outdoor projector by L&L Luce&Light is a powerful and versatile lighting fixture, designed for applications on surfaces such as ceilings, walls, floors, with the option of installation using a spike or anchoring strap. With a power consumption of 8W and a high-intensity LED, this projector is ideal for illuminating facades, architectural details, gardens and outdoor areas, offering warm and comfortable light with a colour temperature of 3000K. The ANTICORODAL aluminium alloy body guarantees excellent resistance to corrosion, while the IP66 protection rating makes it perfect for prolonged use in outdoor environments.

Spot 2.4 Technical Data Sheet
Code: CF2410000050MH

Description: The Spot 2.4 is designed to be a robust and resistant projector, perfect for lighting outdoor environments exposed to atmospheric agents. Its compact design and anthracite finish make it suitable for both residential and commercial contexts, to highlight details or create lighting effects of great visual impact.

Technical Data

Electrical Features:

• Power Consumption: 8W
• Power supply: 230V AC
• Power supply: Built-in power supply

Lighting Features:

• Number and Type of LED: 1 High Intensity Power LED
• Average LED life: 50,000 hours L85 B10 (Ta 25°C)
• LED Color: 3000K, warm white light to create a cozy atmosphere
• Colour Rendering Index (CRI): 80, for good colour rendering and natural lighting
• Binning: 3 step MacAdam, to ensure uniformity in color tone
• Optics: 29°, optical system composed of highly efficient TIR lens for precise distribution of the light beam
• Luminous Flux at Source: 586 lm (3000K)
• Luminous Flux Emitted: 515 lm (3000K, 29° optics)

Mechanical Features:

• Dimensions: Ø60 x 124 mm
• Weight: 700 g
• Finishes: Anthracite finish, obtained through a ceramic nanoparticle painting treatment, with epoxy and polyester coating, for corrosion resistance that exceeds 1000 hours of salt spray
• Fixing: With bracket, screws and dowels for stable installation on various surfaces
• Body Material: ANTICORODAL low copper aluminum alloy body, made by CNC turning processing, for greater corrosion resistance. 5754 aluminum alloy bracket, tumbled and painted
• Screen Material: 4mm extra-clear transparent tempered glass with vitrified silkscreen printing, to ensure chromatic uniformity of light and resistance to scratches and impacts

General Features:

• Protection Grade: IP66, suitable for dust and high pressure water jet resistance, perfect for exposed outdoor environments
• Operating Temperature: -20°C to +45°C
• Impact Resistance Rating: IK07, designed to withstand mechanical impacts
• Energy Consumption Class: F, compliant with EU regulation 2019/2015
• Glow Wire Resistance Test: 960°C
• Insulation Class: Class I
• Walkable: No
• Driveway: No
• Power Cables: 1.5m H05RN-F 3x1.0 Ø7mm neoprene cable included for easy electrical connection
• Protection Systems:
  • IPS (Intelligent Protection System): Protects the device from water infiltration and electrical phenomena such as junction errors, polarity reversals, hotplug, ESD and overvoltages
  • PID (Protective Impedance Device): Protects against accumulation of electrostatic charges and other electrical phenomena external to the system
• Photobiological Safety: Risk Group 1 according to EN 62471:2006, ensuring safety for eyes and skin

Available Accessories:

• WB1001H: Standard scope - anthracite, to create focused light effects
• WB1002H: Asymmetrical spotting scope - anthracite, for a wider and more uniform light distribution
• WP0100: Ground installation spike, ideal for installing the projector in gardens and flowerbeds
• WP1004: Anchoring strap - 5m, to fix the projector on particular structures such as trees or poles
• WP1006H: Ground spike - height 500 mm - anthracite
• WP1007H: Ground spike - height 800 mm - anthracite

Additional Notes:

• Casambi Management (Optional): Available upon request for smart lighting control via the Casambi app, allowing you to customize your lighting directly from a mobile device.

EOL (End Of Line) Test: Tested and approved through end of line tests with verification of correct operation and control of electrical absorption parameters.

The Spot 2.4 is the ideal choice for powerful and versatile outdoor lighting, perfect for enhancing architectural details, gardens and other outdoor areas. With its robust construction, corrosion-resistant finish and the possibility of smart management via Casambi, the Spot 2.4 offers reliability, efficiency and complete control of the lighting.
