S204m c25 circuit breaker 10ka 4

The ABB S204M C25 circuit breaker is designed to protect electrical systems from overloads and short circuits, ensuring reliability and safety in operations.

Main features:

• Rated current (In): 25 A

• Number of poles: 4

• Intervention curve: C (suitable for inductive loads with moderate inrush currents)

• Breaking power:

  • 10 kA according to IEC 60898-1

  • 15 kA according to IEC EN 60947-2

• Rated operating voltage (Ue): 230/400 V AC

• Rated insulation voltage (Ui): 440 V

• Frequency: 50-60 Hz

• Operating temperature: -25°C to +55°C

• Degree of protection: IP20

• Width: 4 DIN modules

• Recess depth: 71 mm

• Additional Features:

• Bidirectional cylindrical terminals: They allow front connection for cables up to 25 mm² (flexible) and up to 35 mm² (rigid), and rear connection for connection bars up to 10 mm².

• Visual status indicator: Green for open contacts, red for closed contacts, reflecting the exact internal position of the contacts.

• Compatibility with accessories: Can be combined with DDA 200 series differential locks and accessorised with additional devices.

Typical applications:

• Protection of electrical circuits in residential, commercial and industrial environments.

• Suitable for the protection of resistive and inductive loads with low inrush current.
