Automatic switch 2 mod. s202m-d6

Main technical specifications:

• Type: Circuit breaker

• Series: S200M (high breaking capacity version, professional)

• Poles: 2P (both poles protected: phase + phase or phase + neutral, depending on the system)

• Rated current (In): 6 A

• Intervention curve: D – for loads with high inrush current , such as motors, transformers or large industrial appliances

• Breaking capacity: 15 kA (high breaking capacity, also suitable for industrial environments)

• DIN modules: 2 mod

• Mounting: On DIN rail, for standard electrical panels

• Rated voltage: 230/400 V AC

✅ Typical usage:

• Industrial or tertiary applications where high current peaks are present at start-up

• Protection of motors, systems with transformers, compressors, pumps, large UPS or welding machines
