Automatic switch 2 mod. s201-c6na

🔧 Main Features

• Model: ABB S201-C6NA

• Product Code: 2CDS251103R0064

• Poles: 1P+N (protected phase + interrupted neutral)

• Rated current: 6A

• Intervention curve: C (suitable for loads with moderate inrush currents)

• Breaking capacity: 6 kA according to IEC EN 60898-1; 10 kA according to IEC 60947-2

• Rated operating voltage: 230/400 V AC

• Frequency: 50/60 Hz

• DIN modules: 2

• Degree of protection: IP20 (IP40 if installed in a panel with cover)

• Operating temperature: -25°C to +55°C

• Mounting: on standard DIN rail

• Supported cable section: up to 25 mm² (flexible) and 35 mm² (rigid)
