Ms132 0.63-1.0a 100k overload switch

The ABB MS132-1.0 motor protection switch (code EP8799) is a compact 45 mm device designed for the protection and manual control of electric motors with rated currents between 0.63 A and 1.0 A. This motor protection switch offers protection against overloads, short circuits and phase failures, eliminating the need for additional fuses.

Main Technical Features

• Current regulation range : 0.63 – 1.0 A

• Rated current (Ie) : 1 A

• Rated operating voltage (Ue) : up to 690 V AC

• Short-circuit breaking capacity (Ics/Icu) : 100 kA at 400 V AC

• Intervention class : 10

• Number of poles : 3

• Degree of protection : IP20 (housing), IP10 (terminals)

• Electrical life : 50,000 cycles

• Mechanical life : 100,000 cycles

• Operating temperature : -25°C to +70°C

• Mounting : on DIN rail (EN 60715)

• Weight : 0.215 kg
