90° bend - Eurostar DI - Stainless steel 316L

90° bend - Eurostar DI - Stainless steel 316L

The Eurostar DI 90° Bend is an essential element for the construction of double-walled flue pipes, designed to offer high performance, durability and compliance with European regulations. Manufactured with high-quality materials, it is ideal for ensuring the correct operation of smoke evacuation systems in various applications.

Main features:

• Material:
  • AISI 316 stainless steel for the internal and external walls, ensuring corrosion resistance and durability over time.
• Double wall design:
  • Composed of two coaxial tubes that form a circular cavity filled with high-density oriented strand rock wool.
• Thermal insulation:
  • The rock wool cavity reduces heat loss and keeps the temperature of the fumes constant, optimising the draught and operation of the flue.
• Safety:
  • The rock wool used has very low biopersistence, helping to protect the health of operators and users.
• Silicone gasket:
  • Available separately on request, it is designed to ensure high sealing and temperature resistance.

Certifications and compliance:

• CE Marking: Complies with EU Regulation No. 305/2011.
• UNI EN 1856/1 standard: Ensures that the product meets the technical requirements for the safe evacuation of smoke.
• Operating temperature:
  • Resistant to high temperatures, ideal for biomass, gas or liquid fuel combustion systems.

Applications:

• Construction of curves in residential and industrial flue systems.
• Ideal for smoke evacuation systems requiring high thermal efficiency and safety.

Advantages:

• Efficient thermal insulation: Ensures the maintenance of the temperature of the fumes, improving draught and reducing condensation deposits.
• Ease of installation: Coaxial design with standardized connections, ideal for modular systems.
• Reliability and Durability: Constructed with high-quality materials to withstand heavy use.
• Health and Safety: Low bio-persistent rock wool, for the benefit of the environment and operators.

Technical specifications:

• Angle: 90°.
• Material: AISI 316 stainless steel.
• Insulation: High density rock wool.
• CE Certification: Complies with UNI EN 1856/1.
• Gasket: Available upon request.

The Eurostar DI 90° Bend is a reliable and safe solution to improve the efficiency and safety of smoke extraction systems. Perfect for residential and industrial applications, it guarantees excellent performance and compliance with industry standards.
