WiFi module kit se1000-wifi01

The SE1000-WIFI01 Wi-Fi Module Kit is designed to enable wireless connection of SolarEdge inverters to a Wi-Fi network, facilitating remote monitoring and management of the PV system.

RF Technical Details:

• Transmit power: 16 dBm

• Receive sensitivity: -93 to -71 dBm

• Antenna Connector: RP-SMA

• EIRP with antenna: 20 dBm

• Outdoor range (in line of sight): up to 400 m

• Indoor range: approx. 50 m

• Maximum power consumption in transmission: 1 W

Main Features:

• Communication Standard: 802.11b/g/n

• Network Security: Supports WPA-PSK, WPA2-PSK and WEP

• Available channels: 13

• Installation: The Wi-Fi module is installed inside the inverter, while the antenna is positioned externally to ensure better signal reception.

• Compatibility: Designed for use with SolarEdge inverters with displays.
