Updown 4.0 - Outdoor Wall Lamp (Code: UD40615MMA)

Updown 4.0 - Outdoor Wall Lamp (Code: UD40615MMA)

The Updown 4.0 is a double emission outdoor wall light, designed for wall installations. It offers an elegant and functional solution for outdoor lighting, with light emission both upwards and downwards. Its robust design and high degree of protection make it ideal for use in outdoor environments exposed to atmospheric agents.

Main features :

• Power consumption : Max 6W
• Power supply : Max 350mA, with series connection.
• Luminous flux :
  • Source : 472 lm (3000K, 350mA)
  • Emitted : 364 lm (3000K, 350mA, 22°)
• LED type : 6 power LEDs with a guaranteed lifespan of 50,000 hours (L90 B10 at 25°C).
• LED color temperature : 3000K (warm light), perfect for creating a welcoming and pleasant atmosphere.
• Optics :
  • UP : 22°
  • DOWN : 22°
• Color Rendering Index (CRI) : 80 , which ensures good fidelity in color reproduction.

Materials and Finishes :

• Body : Made of anodized aluminum , which guarantees resistance to corrosion and durability over time.
• Finish : Grey anodized , with RAL finishes available on request.
• Screen : Made of extra-clear transparent glass , which ensures excellent light transmission.
• Dimensions : 49x49x130 mm
• Weight : 700 g

General characteristics :

• Protection rating : IP65 , ideal for resisting dust and water jets, making it perfect for outdoor environments.
• Resistance level : IK08 , for protection against impacts.
• Operating temperature : -20°C to +45°C .
• Insulation class : Class III , to ensure electrical safety.
• Energy consumption class : F (in accordance with EU regulation 2019/2015).
• Glow wire test : 960°C , confirming the thermal resistance of the device.

Management and protection systems :

• Dimmable : Brightness management available via dimmable power supply (not included).
• Casambi Management : On request, smart control via Casambi app with dedicated electronics.
• Power cables : Including 0.30 m PVC cable FROR 2x0.35 Ø3.5 mm.

Accessories and Options :

• Spacer : Available on request in RAL finish for custom applications.

The Updown 4.0 is an ideal solution for lighting exteriors with style and functionality, offering directional light up and down, with a modern and weatherproof design.
