S.5189.19 PRODUCT DATA SHEET COMPACT ROUND 200 mm - TYPE Walk-over fixture for ground installation. Depth 115 mm. Protection rating IP 67 - MATERIAL CHARACTERISTICS Body in die-cast primary aluminium "Copper Free" EN AB-44100 with high resistance to oxidation. Tumbling process for preparation for the painting phase. 2 mm thick front finishing ring made of AISI 316L stainless steel with a high molybdenum content of 2.5-3%. Screws in A4 stainless steel with a high molybdenum content of 2.5-3%. Annealed silicone gaskets. Extra-resistant double painting carried out in 3 phases: 1) BONDERITE treatment with chemical protection of metal-free fluozirconic material containing ceramic nanoparticles that create a cohesive, inorganic, high-density layer. 2) PRE-POLYMERIZATION cycle with application of epoxy primer with characteristics of overpaintable on the device and high resistance to oxidation thanks to the presence of zinc. 3) POLYMERIZATION cycle with application of polyester powder with high characteristics of resistance to UV rays and atmospheric agents, with resistance to the salt spray test of 1500h. Mechanical resistance of the glass IK 09 Maximum load 1000 Kg-LIGHTING PERFORMANCE 12 mm thick tempered acid-etched protective glass of the Weissglass sodium-calcium type with high transmittance value +12% (compared to a common glass). Light source, with fixed lamp position. Efficiency 18% Compact electronic power supply for longer life and stability of the lamp and reduced energy consumption.-LOW SURFACE TEMPERATURE Weissglass glass capable of absorbing less energy than traditional glass thanks to its high transmittance. Glass temperature 60°C (Ta 25°C) Electronic power supply with lower heat development. Optimization of the layout of the components inside the product allows excellent heat dissipation, keeping the internal temperature within admissible limits.-FORMWORK FOR INSTALLATION AND MAINTENANCE Supplied with polypropylene formwork designed for cable entry from 4 sides which allows: 1) easy wiring; 2) housing the IP68 quick connector; 3) easy removal of the device for maintenance.-WIRING Piece of H07RN-F type power cable closed by means of the PG 13.5 cable gland (Ø 6÷12 mm), sealed with two-component epoxy resin and wired internally with the cables covered by protective silicone sheaths. Supplied with M20 (Ø 5÷14 mm) IP68 quick connector for single pass-through connection, to be housed inside the formwork. Front lamp change without completely extracting the device. With 230V-12V electronic transformer in IP67 box. Insulation class: CLASS I Available colours: STAINLESS STEEL (code 19) Weight: 3.27 Kg Glow Wire test: 750°C Devices supplied complete with lamp.
