Constant Current Electronic Power Supply for LED WP01-P STD 18W 700mA

The WP01-P STD 18W 700mA power supply is designed to efficiently power constant current LED lighting systems. With a compact and robust design, it is ideal for independent use in indoor environments, ensuring safety, efficiency and advanced protections against overloads and short circuits.

Main features:

• Independent use : Designed for indoor use , with IP20 protection rating, suitable for indoor applications in residential or commercial environments.

• Class II Insulation : Provides protection against electric shock from both direct and indirect contact, ensuring greater operational safety.

• Passive PFC : Equipped with passive power factor correction , which improves energy efficiency by reducing consumption.

• Advanced Protections : The power supply includes protections against short circuits , overloads and extra mains voltages , ensuring safe and stable operation.

• Connections : Supplied with terminal cover and cable clamp , with opposite screw terminals for a safe and stable connection of the input and output cables.

Technical specifications:

• Output power : 12-18W
• Output voltage : 17-26V
• Output current : 700 mA constant
• Maximum output voltage : 36V
• Power Factor (PF) : 0.9
• Efficiency : 87%
• Input voltage : 220-240V AC
• Frequency : 50/60 Hz
• Maximum input current : 0.11A

Operating conditions:

• Ambient temperature (ta) : -20/+50 °C
• Maximum temperature (tc) : 75°C

Dimensions and Weight:

• Dimensions : 89x42x23 mm
• Weight : 0.07 Kg

Cable section:

• Input : 0.75-1.5 mm²
• Output : 0.5-1.5

Packaging:

• Inner/Master : 1/100

Advantages:

• Compact design : Thanks to its small size, the power supply is easy to install even in tight spaces.

• Comprehensive Protection : Offers built-in protection against overload, short circuit and overvoltage, ensuring greater reliability.

• Energy Efficiency : With a power factor of 0.9 and an efficiency of 87%, the power supply is ideal for reducing energy consumption and improving overall savings.

The WP01-P STD 18W 700mA is the ideal solution for LED systems requiring constant current, combining safety, efficiency and a compact design to suit a variety of indoor lighting applications.
