Sts Expansion card 8 inputs 2 relay outputs

The STS 8 Input 2 Relay Output Expansion Card is an expansion module used to increase the number of inputs and outputs available in a control or automation system, such as those used in security, access control, industrial automation or home automation systems. This card allows you to add additional functionality to the main system, offering flexibility in the management and control of different devices.

Main features:

• Brand: STS
• Product type: Expansion card
• Number of inputs: 8 digital inputs
• Number of outputs: 2 relay outputs
• Output Function: Relay outputs for controlling external loads such as lights, motors, electric locks, alarms, etc.
• Compatibility: Can be used with various control and automation systems (home automation, security, access control, etc.)

Product Description:

The STS 8-input, 2-output relay expansion board is designed to extend the capabilities of a control system by providing additional input points for sensors, buttons or other input devices and relay outputs for direct control of electrical loads or devices. The digital inputs can be used to detect activation signals from sensors or switches, while the relay outputs allow direct control of various devices.

Technical specifications:

• Number of inputs: 8 digital inputs, can be used to connect sensors or other signaling devices.
• Number of outputs: 2 relay outputs, designed to control external devices.
• Output type: Normally open (NO) or normally closed (NC) relay, depending on the configuration.
• Power: The board may require a specific power supply voltage (usually between 12V and 24V DC, but it depends on the specific model).
• Connections: Clamp terminals for easy wire connection.

Usage:

• Industrial Automation: Expands the functionality of a PLC or other industrial controller to manage multiple sensors, actuators, and control devices.
• Home Automation and Environmental Control: Used to integrate input devices such as motion sensors, switches and buttons with home automation systems.
• Security Systems: Increase the capacity of a central alarm or access control unit to monitor multiple zones or security devices.

Advantages:

• Expandability: Allows you to easily increase the number of devices a system can manage without having to replace the main control unit.
• Flexibility: Compatible with a wide range of applications and devices, from home installations to professional security systems.
• Ease of integration: Easily integrated with existing systems through standard connections and programmable configurations.

Notes:

• System Compatibility: Verify that the expansion card is compatible with the control system in use.
• Installation: Installation by a qualified technician is recommended to ensure proper connection and operation.
• Setup: You may need to configure your card using specific software or tools depending on your system needs.
