Dimmable Electronic Power Supply for LED WP01-P-D STD 8W 350mA - Internal Use

The WP01-PD STD 8W 350mA is a dimmable electronic power supply designed for LED applications, perfect for independent use in indoor environments. Thanks to its advanced features, it allows you to adjust the brightness precisely and reliably through different control modes. Ideal for installations that require flexibility in lighting management, this power supply is easy to install and safe to use.

Main features:

• Use : Designed for indoor use , with IP20 protection, compliant with Class II for electrical insulation, ensuring safety against electric shock for direct and indirect contact.

• Active PFC : Integrates active power factor correction ( PFC ), optimizing energy efficiency and reducing consumption.

• Protections : Equipped with protections against short circuits , overloads , extra mains voltages , and overheating , offering safe and long-lasting operation.

• Dimmable : Support two brightness adjustment modes:

  • PUSH : Allows brightness adjustment from 0-100% using an external button. Short press (1 sec) to adjust the light intensity. Memorizes the last state before switching off.
  • 0/1-10V or Potentiometer : Brightness control through a 0/1-10V signal or a 100kOhm potentiometer for linear and precise regulation.

• PUSH Function : It can manage up to 50 power supplies without the need for a synchronization cable. The maximum cable length for PUSH control is 15 meters . It is recommended to use normally open buttons, without indicator lights.

• Connections : Equipped with spring terminals at the input and output, supplied with terminal cover and cable clamp , simplifying installation and ensuring a safe and stable connection.

Technical specifications:

• Input voltage : 220-240V AC
• Input frequency : 50/60 Hz
• Maximum input current : 0.045A
• Output voltage : 6-30V DC
• Output current : 350 mA constant
• Rated power : 2-10W
• Efficiency : 80%
• Power Factor (PF) : 0.9

Operating conditions:

• Ambient temperature (ta) : -20/+50 °C
• Maximum operating temperature (tc) : 85 °C

Dimensions and Weight:

• Dimensions : 88x53x25 mm
• Weight : 0.09 kg

Wiring:

• Input cable section : 0.75-1.5 mm²
• Output cable section : 0.75-1.5 mm²

Packaging:

• Format : inner/master 1/100

The WP01-PD STD 8W 350mA Dimmable Electronic Power Supply represents a versatile and safe solution for managing LED lighting, with advanced regulation functions and integrated protections. Ideal for indoor environments, it offers reliable performance and precise control of light intensity.
