FTE DSCR41 Multiswitch dSCR 4 in 1 Derivative

The FTE DSCR41 Multiswitch is an advanced device for satellite signal distribution, designed to support up to 16 pilot frequencies on a single derived output. Thanks to the dSCR protocol, this multiswitch allows you to create systems with multiple SCR or dCSS outputs using a single cable, maintaining high signal quality.

Main features:

• Description : Cascaded dSCR multiswitch for 16 user bands.
• Small size : Compact design allows installation in small flush-mounted boxes and cable routing with slight curves, without compromising signal quality.
• Compatibility : Compatible with SKY Italia and supports all SCR standards.
• Automatic Gain Control (AGC) : Maintains stable signal quality regardless of level variations.
• Supported protocols :
  • SCR EN 50494
  • dCSS EN 50607
• Pilot Outputs : Up to 16 pilot outputs for each dSCR derived output.

Technical specifications:

• Frequencies : 950-2150 MHz
• SAT inputs : 4
• SAT pass-through outputs : 4
• Line pass attenuation : 3 dB
• dSCR derived outputs (SCR+dCSS) : 1
• Connector type : F female
• dSCR user bands (SCR+dCSS) : 16
• dSCR output level : 85 dBµV
• Return loss : 12 dB
• Derivative attenuation : Not applicable, thanks to automatic gain control (AGC)
• Band and polarity selection : DISEqC 1.0 (unidirectional)
• Maximum consumption :
• Power supply : From STB or via PWR2V or PS20-3000 + INDSCR
• Dimensions : 90 x 80 x 40 mm

Strengths:

• Easy installation : The compact size allows for easy and versatile installation even in tight spaces.
• Efficient Signal Distribution : Supports complete signal distribution with both the current SCR standard and the new dCSS standard.
• Extended Compatibility : Ideal for use with satellite systems compliant with SCR and dCSS standards, including SKY Italia.
• Automatic Gain Control : Ensures optimum signal quality, regardless of input variations.

Applications:

• Ideal for providing complete satellite signal distribution with the current SCR standard and the new dCSS.
• Thanks to the dSCR protocol, it is possible to create systems with multiple SCR or dCSS outputs using a single cable, simplifying configuration and reducing installation costs.
