Power supply 24v 5a en 54-4 / en 12101-1

Notifier Power Supply 24V 5A EN 54-4 / EN 12101-1

• Output voltage: 24V DC
• Output current: 5A
• Certifications: EN 54-4, EN 12101-1
• Type: Power supply for fire and smoke evacuation systems
• Input voltage: 230V AC
• Battery Backup: Supported
• Status indication: LED for operational monitoring
• Protection: Against overloads and short circuits
• Mounting: On a frame or wall
• Weight: Approx. 3.5kg

Product Description:

The Notifier Power Supply 24V 5A is specifically designed to provide a continuous and reliable power source for fire protection and smoke extraction systems . Compliant with EN 54-4 and EN 12101-1 standards, this power supply ensures the safe and continuous operation of safety devices in critical conditions, such as control panels for smoke detectors, fire alarms, and smoke extraction systems.

• EN 54-4 and EN 12101-1 compliant : These certifications ensure that the power supply complies with European standards for fire alarm and smoke extraction systems, offering high safety and reliable protection in the event of an emergency.

• Output Voltage 24V DC : Designed to power fire and evacuation equipment that operates on 24V voltage, such as fire control panels, sirens and detectors.

• 5A Output Current : With the ability to deliver up to 5A of current, this power supply is ideal for powering multiple devices within a complex fire safety system, ensuring efficient power distribution.

• Battery Backup Support : The power supply is equipped to connect a battery backup , ensuring that the system remains active even if the main power supply fails. This feature is essential for business continuity in emergency scenarios.

• Built-in Protection : The power supply is equipped with overload and short circuit protections, preventing damage to connected devices and ensuring safe and reliable operation.

• LED Monitoring : Includes LED indicators that provide at-a-glance information about the system's operating status, making it easy to monitor the power supply and diagnose any problems.

Applications:

• Fire Detection and Alarm Systems : Ideal for powering smoke detectors, control panels and fire alarm systems.
• Smoke Exhaust Systems : Designed to provide power to ventilation control systems to evacuate smoke and heat in the event of a fire.
• Industrial Security Systems : Suitable for any installation requiring a continuous, certified power supply for fire safety systems.

Technical features:

• Output voltage: 24V DC
• Output current: 5A
• Certifications: EN 54-4, EN 12101-1
• Input voltage: 230V AC
• Protection: Overload and short circuit
• Battery Backup: Supported (battery not included)
• LED Indications: Power status monitoring
• Weight: Approx. 3.5kg

Advantages:

• Regulatory compliance : Ensures safe and certified operation according to European regulations for fire safety and smoke evacuation.
• Reliability : Designed to provide continuous and reliable power, with protection against overloads and short circuits.
• Battery Backup : The battery backup provision ensures that the security system remains operational even in the event of a main power failure.
• Ease of Monitoring : LED indicators provide instant feedback on system status, making maintenance and monitoring easy.

Included in the package:

• 1x Notifier Power Supply 24V 5A
• User and installation manual
