Klp 40-1200 m

The KLP 40-1200 M is an in-line circulation pump produced by DAB Pumps, designed for the movement of hot or cold water in civil and industrial systems, such as heating, air conditioning, refrigeration and domestic hot water systems.

Main Features:

• Pump Body and Motor Support: Made of cast iron, they guarantee strength and durability over time.

• Impeller: Made of technopolymer, it offers corrosion resistance and lightness.

• Mechanical Seal: Carbon/ceramic, ensures reliable operation and reduces leakage.

• Motor: Two-pole asynchronous, with built-in thermal-amperometric protection and permanently inserted capacitor in the single-phase version.

• Flanged ports: PN 10, equipped with threaded holes for the installation of control pressure gauges.

Performance:

• Flow rate: Up to 67 m³/h.

• Head: Up to 13.7 metres.

• Liquid Temperature: -15°C to +120°C.

• Operating Pressure: Up to 10 bar (1000 kPa).

Applications:

The KLP 40-1200 M is ideal for:

• Heating systems.

• Air conditioning and refrigeration systems.

• Distribution of domestic hot water.

Dimensions and Weight:

• Length: 250 mm.

• Connection: DN 40.

• Weight: Approximately 23.2 kg.
