Freespace ds 16f loudspeaker white

Bose FreeSpace DS 16F – In-Ceiling Speaker (White)

The Bose FreeSpace DS 16F is an in-ceiling speaker designed to deliver clear, balanced audio reproduction in commercial and professional environments. Elegant and discreet in its white finish, it integrates perfectly into false ceilings, ensuring excellent acoustic performance without impacting the aesthetics of the environment.

🎵 Sound quality

Equipped with a 2.25" (57 mm) full-range driver, this speaker ensures clear reproduction of both voices and background music. The wide coverage (140° conical) allows for even sound diffusion, reducing the need for numerous installation points.

⚙️ Technical performance

• Rated power: 16 watts (64 watts peak)

• Frequency response: 95 Hz – 17 kHz (±3 dB)

• Sensitivity: 84 dB SPL (1 W @ 1 m)

• Maximum sound pressure: up to 102 dB SPL (peak)

• Multi-tap transformer for 70/100 V systems, with adjustments from 1 to 16 W

• Compatibility with 8 ohm impedance (transformer bypass)

🧱 Structure and installation

The speaker body is made of durable material (PC/ABS), while the powder-coated steel grille can be customized with paint to match the color of the ceiling. Integrated mounting arms make installation quick and easy, even in suspended ceilings.

📐 Dimensions

• Flange outer diameter: 239mm

• Mounting hole: 203mm

• Depth: 176 mm

• Weight: 1.9 kg

🏢 Ideal for environments such as:

• Shops and boutiques

• Restaurants and bars

• Hotel, resort and lobby

• Offices, waiting rooms, meeting rooms

• Schools, museums, public spaces

The Bose FreeSpace DS 16F is the perfect solution for those who want a discreet, efficient audio system with the sound quality guaranteed by Bose, perfect for environments where the balance between design and performance is fundamental.
