Ds201 l differential circuit breaker 4.5ka 1p+n a c16 30ma 2mod

The ABB DS201 L C16 AC30 residual current circuit breaker is a compact and reliable protection device, designed for residential and light commercial applications.

🔧 Main Features

• Model: DS201 L C16 AC30

• ABB Product Code: 2CSR245041R1164

• Type: Residual Current Circuit Breaker (RCBO)

• Poles: 1P+N (protected phase + neutral)

• Rated current (In): 16 A

• Intervention curve: C (suitable for loads with moderate inrush currents)

• Differential sensitivity (IΔn): 30 mA

• Differential type: AC (sensitive to sinusoidal alternating fault currents)

• Breaking capacity: 4.5 kA according to EN 61009-1

• Rated voltage: 230 V AC

• Frequency: 50/60 Hz

• Number of DIN modules: 2

• Degree of protection: IP20

• Operating temperature: -25°C to +55°C

• Mounting: DIN rail
