Differential circuit breaker co.1p+n c13 4.5ka ac/0.03 2m

The Gewiss GW94011 is a compact differential magnetothermal switch from the MDC 45 series, designed for the protection of electrical circuits from overloads, short circuits and dispersion to earth.

Main features:

• Number of poles: 1P+N
• Intervention curve: Curve C
• Rated current (In): 13 A
• Rated differential current (IΔn): 30 mA
• Differential protection type: AC (sensitive to sinusoidal alternating currents)
• Breaking power:
  • According to IEC/EN 61009-1: 4.5 kA
  • According to IEC/EN 60947-2: 6 kA
• Number of modules: 2
• Rated voltage: 230/240 V AC
• Nominal frequency: 50/60 Hz
• Energy limitation class: 3
• Reference standards: IEC/EN 61009-1, IEC/EN 61009-2-1
• Operating temperature: -25°C to +60°C (with derating of nominal current for T > 30°C)
• Compatibility with electrical auxiliaries: Yes
• Compatibility with ReStart system: Yes
